HELLA 8KV 177 785-007 Cable Junction Box - Flat Plug-in Connector 6.3mm - 12-pin connector - Number of

Item Attributes: Width: 158 mmHeight: 63 mmDepth: 99 mmMounting Type: Flat Plug-in ConnectorConnecting thread: 8 x M16 x 15 / 3 x M20 x 15 / 1 x M25 x 15Prot.type (IP Code): IP69KConnector type: 8x4 + 3x8 + 1x20Mounting Bores Distance: 150 mmNumber of connectors: 76Number of inlets/outlets: 12Number of bores: 2Bore Ø: 5.5 mmHousing Type: Housing with Plastic LidMaterial: PA (polyamide)Number of pins: 12 -pin connectorSocket Width: 6.3 mmRegistration Type: ADR/GGVSSVHC: 84-74-2; Dibutyl phthalate (DBP) / 80-05-7; 44-isopropylidenediphenol / 96-45-7; Imidazolidine-2-thione; (2-imidazoline-2-thiol)Assembly by qualified personnel required!

If different multi-core cables are to be linked together the overview can quickly get lost. For these cases the HELLA cable connector boxes offer a safe and easy-to-use bundling solution that creates order. The lockable fire-resistant construction provides the necessary protection for the individual wires.

Cable Junction Box;HELLA;84-74-2; Dibutyl phthalate (DBP);55mm;PA (polyamide);Flat Plug-in Connector;76;99mm;80-05-7; 44-isopropylidenediphenol;8 x M16 x 15;3 x M20 x 15;Housing with Plastic Lid;12-pin connector;12;8x4 + 3x8 + 1x20;1 x M25 x 15;IP 69K;150mm;96-45-7; Imidazolidine-2-thione; (2-imidazoline-2-thiol);63mm;63mm;158mm;2;ADR/ GGVS Checked;
