Description
Item Attributes: Operating temperature from: -40 °COperating temperature to: +80 °CProt.type (IP Code): IP5K0Voltage: 12 VCharging Rate: 6.7 ANumber of pins: 2 -pin connectorSVHC: 7439-92-1; LeadAssembly by qualified personnel required!pplication: The linear actuator is used for the electrical locking unlocking or closing function of the closing and flap systems in automotive and industrial applications.Examples of applications in mechanisms include: Electrical locking/unlocking Electrical closing Electrical opening and closing of all doors (locking systems) flaps sunroofs seats covers bonnets glove compartments etc.Design and function: There is an electric motor installed in the two laser-welded polyamide housing halves. As a result of the electric motor being supplied with current via pin 1 and pin 2 it moves a spindle gear which causes the tappet to retract or extend depending on the direction of rotation. The current supply with plus at pin 1 and minus at pin 2 causes the tappet to extend. The current supply with minus at pin 1 and plus at pin 2 causes the tappet to retract. The stability of the retracted/extended locking positions is achieved by the short-circuited motor following successful actuation. A PolySwitch (PTC) integrated in the motor provides thermal overload protection. In addition it is possible to equip the actuators with an automatic return function (retracting or extending) by way of a mainspring. Accessories: The comprehensive range of accessories for the linear actuator includes a wide variety of different connecting elements. These allow the straightforward integration of the actuator in the application without additional development expenditure being necessary.OE references: VALMET 1017169MB-01
