Description
As a supplier of OE-quality parts, DENSO brings precision engineering to the aftermarket. Every DENSO component delivers performance you can rely on — engineered to meet or exceed strict original equipment standards for fit, function and durability.
DENSO provides in-tank fuel pumps which are the most widely used and are located within the fuel tank itself. The positioning of an in-tank fuel pump means the noise from the electric motor is reduced and the pump is continuously supplied with fuel, keeping the motor lubricated and cool. When the impeller of an in-tank fuel pump rotates, the blade moves around the impeller. This creates a swirling motion inside the pump which then passes fuel around the motor, forcing the check valve upwards to supply fuel to the fuel pipe.
The turbine technology inside DENSO’s in-tank fuel pumps offers greater supply capacity and better control over the discharge volume, meaning the performance can be adjusted to suit the operating conditions of particular engines.
FEATURES
- Turbine technology minimizes pressure pulsation and noise
- Accurate pressure measurement improves performance
- All-new parts mean DENSO fuel pumps have a longer lifetime
- Higher operation speeds with less required current
- Highest quality and manufacturing precision enables long and stable performanc
OE QUALITY STANDARDS
- Pressure is continuously measured within our in-tank fuel pumps to ensure the requirements are met for each engine type and specification
INNOVATIVE DESIGN
- Our turbine technology with a V-shaped internal impeller helps to minimize motor noise and maintain the performance of DENSO fuel pumps for a longer lifetime
RELIABLE PERFORMANCE
- DENSO fuel pumps are specifically made to fit the right application, and both manufactured and tested with OE standards to meet exact fuel pressure demands. Therefore, you can be sure they will deliver high performance for a longer lifetime
WARRANTY
- 2 Years Unlimited Mileage
COMPETITOR CROSS REFERENCES
- DENSO: 1951319020, DFP0103
OEM CROSS REFERENCES
- TOYOTA: 2322115040, 2322116490, 2322122030, 2322122140, 2322123010, 2322174020
TECHNICAL DATA
| Current (I) | 5.5A |
| Delivery Quantity | 80 |
| Fitting Position | In fuel tank |
| Gross Weight (g) | 550 |
| Height Incl Packaging (mm) | 120 |
| IN | OB |
| Indication Reman Part | New |
| Length Incl Packaging (mm) | 205 |
| MAM Prodcode | FPUM |
| MAM Section | Fuel & Engine Management |
| MOQ customer | 1 |
| Net Weight (g).1 | 500 |
| Number of Poles | 2 |
| Operating Mode | Electric |
| Out | Pipe ø 8.8 mm |
| Packaging Material Inner | LDPE |
| Packaging Material Outer | PAP 21 |
| Packaging Units | 1 |
| Packing Weight (g).1 | 100 |
| Pressure (bar) | 2.94 |
| Quality | DENSO |
| Supplementary Article/Supplementary Info | Without strainer |
| Tecdoc ID | 0066 |
| Type | H38 |
| Type of Packing | Carton Box |
| Width Incl Packaging (mm) | 115 |
