Description
Need extra reach without going too long? The Bumblebee EV 7.5m Type 2 to Type 2 cable offers the perfect middle ground.
Providing 7kW charging at 32A single phase, it’s ideal for shared driveways, awkward parking angles, or when your charging point is slightly out of reach. Designed for strength and flexibility, this cable is built to withstand daily use and varying weather conditions, giving you reliable charging wherever you are.
GENERAL
| Cable Specifications | 5*6 mm²+1*0.5 mm² |
| Cable O.D. | 16±0.5 mm |
| Cable Overall Length | Available in 5.0 m, 7.5 m and 10.0 m |
| Power Options | Available in 7.4 kW, 11 kW or 22 kW |
| Operating Temperature | -30 °C to +50 °C |
| Insulation Resistance | 500 MΩ (500V DC) |
| Contact Resistance | 5 mΩ Max. without wire |
| Insertion force | 100 N Max |
| Standard | EN 62196-2:201 |
PROTECTION
| Ingress Protection | IP54 (with protective cap) |
CHARGING
| Connector on vehicle side | Type 2 (IEC 62196-2) |
| Connector on infrastructure side | Type 2 Socket (IEC 62196-2) Electronic lock with permanent lock option |
| Rated Current | 6 A 1 phase to 32 A 3 phase |
| Maximum Output Current | 32 A |
| Rated Voltage | 480 V |
| Rated Frequency | 50 Hz |
| Withstanding Voltage | 2500V AC (50/60 Hz@1 min) between L.N.PE |
Registered by NAPIT and approved by both OZEV and Energy Savings Trust, the company was created to bring industry-leading customer service and support to the electric vehicle charging infrastructure market.
