HELLA 2XD 013 979-021 LED-Strobe-type Beacon - RotaLED Compact - 12/24V - Yellow

Item Attributes: Mounting Type: Magnet MountLight Design: LEDLamp Type: LEDVoltage: 12 V / 24 VHeight: 118 mmOuter Diameter 1: 165 mmLight Function: With flashing warning signalLight colour: YellowNumber of LEDs: 16Connection type inlet: Cigarette LighterProt.type (IP Code): IP6K7 / IP6K9KRegistration Type: SAE / ADR/GGVSFulfils ECE norm.: R10 / R65Lens Colour: YellowHousing Colour: BlackFlash rate per minute: 122Power consumption: 10 WHousing material: ABS (Acrylonitrile-Butadiene-Styrene Copolymerisate)Operating temperature from: -40 °COperating temperature to: +60 °CWeight: 420 gCable: 200 mmDiffusing Lens Material: PC (Polycarbonate)Reverse polarity protection: YesPermissible Max. Speed: 120 km/hQuantity: 1Supplementary Article/Info 2: Electromagnetic Compatibility (EMC)Assembly by qualified personnel required!

The RotaLED Compact beacon is available as a flashing or rotating version. The signal is generated by means of an electronic concept and thus without moving parts. The beacon can be connected to an operating voltage of 10 - 30 V and has an impact-resistant polycarbonate light cover. The height is approx. 118 mm (F) to 164 mm (FL) depending on the design. The RotaLED Compact beacon meets the requirements of IP 67 and IP X9K and is therefore dust-tight and resistant to high-pressure cleaners. Even short-term immersion up to 1 metre under water is possible. The product is attached to the vehicle by means of screws in the case of fixed mounting or by means of a flexible pipe socket or magnetic adapter in the case of the other variants. The beacon is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots. The RotaLED Compact is the successor to the halogen beacon series Rotafix Rotaflex and Rota Compact and makes a 1:1 exchange to LED technology possible.

OE references: DAF 1551351; FARESIN ME11080D61; HYUNDAI 21WD-01401; SENNEBOGEN 230503; VOLVO 1 524 024 2; VOLVO 15240242; VOLVO VOE15240242

Rotating Beacon;HELLA;RotaLED Compact;With flashing warning signal;120km/h;+60°C;165mm;ECE-R10;12V;IP6K7;SAE;10W;16;PC (Polycarbonate);24V;200mm;2XD 013 979-021;Black;Yellow;118mm;-40°C;122;DIN ISO 4165;ADR/ GGVS Checked;IP6K9K;ABS (Acrylonitrile-Butadiene-Styrene Copolymerisate);Yes;1;Magnet Mount;420g;Yellow;LED;ECE-R65;Electromagnetic Compatibility (EMC);
