HELLA 2XD 012 980-001 LED-Strobe-type Beacon - K-LED Blizzard - 12/24V - Yellow

Item Attributes: Mounting Type: Bolted / mountingLight Design: LEDLamp Type: LEDVoltage: 24 V / 12 VHeight: 88 mmOuter Diameter 1: 149 mmLight Function: With flashing warning signalLight colour: YellowNumber of LEDs: 10Plug: FlachsteckerProt.type (IP Code): IP6K7 / IP6K9KRegistration Type: ADR/GGVS / SAEFulfils ECE norm.: R65 / R10Lens Colour: Crystal clearHousing Colour: SilverPower consumption: 16 WFlash rate per minute: 121Housing material: AluminiumOperating temperature from: -40 °COperating temperature to: +60 °CWeight: 830 gCable: 150 mmDiffusing Lens Material: PC (Polycarbonate)Reverse polarity protection: YesQuantity: 1Supplementary Article/Info 2: Electromagnetic Compatibility (EMC)LED colour: YellowObserve mounting informationAssembly No.: up to 4Assembly by qualified personnel required!

The K-LED Blizzard beacon generates an intensely perceptible double flash signal that provides an attention-grabbing 360° warning effect. The beacon can be connected to an operating voltage of 10-30 V and has an impact-resistant polycarbonate light cover. Depending on the design the height is approx. 88 mm (F) to 132 mm (FL). The housing is passivated and then coated with powder paint which provides a high level of protection against aggressive media such as salts and alkalis. The K-LED Blizzard meets the requirements of IP67 and IP9K and is therefore dust-tight as well as resistant to high-pressure cleaners. Even short-term immersion up to 1 metre under water is possible. The product is attached to the vehicle by means of screws in the case of fixed mounting or by means of a flexible pipe socket or magnetic adapter in the case of the other variants. The beacon is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots. The K-LED Blizzard is the successor of the beacon series K-LED FO and makes a 1:1 exchange to the new version possible.

OE references: AEBI 1069182-4; BUCHER 7020725; DAF 154 1963; DAF 1561963; FAUN 5644996; HUMBAUR 409.00217; IVECO 500051178; KAMAG 61301464; KEMPF 142687; LANGENDORF 1315938; LIEBHERR 13161809; MAFI 0005800729; SCANIA 20223245; SCANIA 2870468; SPIERINGS 1073270; TATRA TW05834

Strobe-type Beacon;HELLA;K-LED Blizzard;Bolted;ADR/ GGVS Checked;LED;150mm;ECE-R65;10;SAE;With flashing warning signal;Yellow;121;IP6K7;-40°C;10W;Aluminium;Silver;PC (Polycarbonate);1;Crystal clear;88mm;24V;Flachstecker;ECE-R10;IP6K9K;+60°C;830g;Yes;Electromagnetic Compatibility (EMC);2XD 012 980-001;149mm;12V;
