HELLA 2XD 011 557-701 LED-Strobe-type Beacon - K-LED 2.0 F - 12/24V - Yellow

Item Attributes: Light Design: LEDLamp Type: LEDMounting Type: BoltedVersion: Airport BeaconVoltage: 24 V / 12 VOuter Diameter 1: 169 mmSupplementary Article/Info 2: Electromagnetic Compatibility (EMC)Height: 88 mmLight Function: With flashing warning signalLight colour: YellowNumber of LEDs: 20Plug: Blade TerminalProt.type (IP Code): IP6K7 / IP6K9KFulfils ECE norm.: R10LED colour: WhiteLens Colour: YellowHousing Colour: SilverRotating beacon RPM: 75 1/minFlash rate per minute: 75Power consumption: 30 WHousing material: AluminiumOperating temperature from: -40 °COperating temperature to: +60 °CWeight: 885 gCable: 200 mmDiffusing Lens Material: PC (Polycarbonate)Quantity: 1Assembly by qualified personnel required!

The K-LED 2.0 beacon provides both a rotating and a flashing warning signal in one product. The signal is generated by means of an electronic concept and thus without moving parts and offers 16 different flash sequences. Thanks to the integrated "day/night mode" the brightness is adjusted to the ambient light by means of a sensor. This ensures increased visibility during the day and the avoidance of glare at night. The beacon can be connected to an operating voltage of 10 - 32 V. It is also very flat and has an impact-resistant polycarbonate light bonnet that protects against shocks. The height of the K-LED 2.0 is approx. 87.6 mm (F) to 160.6 mm (R) depending on the design. It meets the requirements of IP67 and is therefore dustproof and can be immersed in water for short periods. The product is attached to the vehicle by means of screws in the case of fixed mounting or by means of a pipe socket or magnetic adapter in the case of the other variants. The beacon is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots.

OE references: AEBI 1218718-0; BUCHER 1076553; FAUN 5184377; GOLDHOFER 126382; MAFI 0005800741; ROSENBAUER 56683A

Rotating Beacon;HELLA;K-LED 2.0;Bolted;-40°C;75;1;IP6K7;885g;PC (Polycarbonate);24V;Yellow;2XD 011 557-701;Aluminium;169mm;LED;Airport Beacon;Silver;Flachstecker;Electromagnetic Compatibility (EMC);IP6K9K;Yellow;88mm;30W;200mm;751/min;ECE-R65;ECE-R10;20;With flashing warning signal;+60°C;12V;
