HELLA 2XD 011 557-601 LED-Strobe-type Beacon - K-LED 2.0 F - 12/24V - Yellow

Item Attributes: Mounting Type: BoltedLight Design: LEDLamp Type: LEDVoltage: 12 V / 24 VOuter Diameter 1: 169 mmHeight: 88 mmLight Function: With flashing warning signalLight colour: YellowNumber of LEDs: 20Plug: DEUTSCH plugProt.type (IP Code): IP6K9K / IP6K7Registration Type: SAE / ADR/GGVSFulfils ECE norm.: R65 / R10Lens Colour: YellowHousing Colour: YellowRotating beacon RPM: 122 1/minFlash rate per minute: 122Power consumption: 30 WHousing material: AluminiumOperating temperature from: -40 °COperating temperature to: +60 °CCable: 300 mmDiffusing Lens Material: PC (Polycarbonate)Weight: 850 gQuantity: 1Supplementary Article/Info 2: Electromagnetic Compatibility (EMC)LED colour: WhiteAssembly by qualified personnel required!

The K-LED 2.0 beacon provides both a rotating and a flashing warning signal in one product. The signal is generated by means of an electronic concept and thus without moving parts and offers 16 different flash sequences. Thanks to the integrated "day/night mode" the brightness is adjusted to the ambient light by means of a sensor. This ensures increased visibility during the day and the avoidance of glare at night. The beacon can be connected to an operating voltage of 10 - 32 V. It is also very flat and has an impact-resistant polycarbonate light bonnet that protects against shocks. The height of the K-LED 2.0 is approx. 87.6 mm (F) to 160.6 mm (R) depending on the design. It meets the requirements of IP67 and is therefore dustproof and can be immersed in water for short periods. The product is attached to the vehicle by means of screws in the case of fixed mounting or by means of a pipe socket or magnetic adapter in the case of the other variants. The beacon is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots.

OE references: LIEBHERR 1 169 357 7

Rotating Beacon;HELLA;K-LED 2.0;122;Yellow;850g;1;2XD 011 557-601;30W;20;169mm;IP6K9K;300mm;12V;-40°C;SAE;LED;IP6K7;DEUTSCH plug;ECE-R65;PC (Polycarbonate);Yellow;With flashing warning signal;+60°C;24V;Bolted;Yellow;Electromagnetic Compatibility (EMC);ECE-R10;1221/min;Aluminium;88mm;ADR/ GGVS Checked;
