HELLA 2RL 012 983-311 LED-Rotating Beacon - K-LED 1.2 - 12/24V - Blue

Item Attributes: Height: 123 mmMounting Type: BoltedLight Design: LEDOperating temperature from: -40 °COperating temperature to: +60 °CRegistration Type: ADR/GGVSProt.type (IP Code): IP67 / IPX9KVoltage: 24 V / 12 VCharging Rate: 0.8 A / 1.6 ANumber of LEDs: 16Light functions: 1Outer Diameter 1: 169 mmRotating beacon RPM: 123 1/minFulfils ECE norm.: R10 / R65Housing Colour: SilverHousing material: AluminiumWeight: 850 gCable: 1500 mmLED colour: WhitePower consumption: 20 WLight Function: With rotating warning signalLens Colour: BlueQuantity: 1Diffusing Lens Material: PC (Polycarbonate)Reverse polarity protection: YesLamp Type: LEDSupplementary Article/Info 2: Electromagnetic Compatibility (EMC)Light colour: BlueAssembly by qualified personnel required!

The K-LED 1.2 beacon has a larger light emission surface due to its double light system achieving a large warning effect. The signal is generated by means of an electronic concept and therefore without moving parts. The beacon can be connected at an operating voltage of 10 - 30 V. It has an impact-resistant polycarbonate light bonnet and the height is approx. 115.5 mm (F) to 196.5 mm (R) depending on the design due to the double light system. The housing of the K-LED 1.2 is passivated and then coated with powder coating which provides a high level of protection against aggressive media such as salts and alkalis. The beacon meets IP6K7 and IP6K9K requirements and is therefore dust-tight and suitable for high-pressure cleaning. Even short-term immersion up to 1 metre under water is possible. The product is fixed to the vehicle by means of screws or by means of a pipe socket adapter. A magnet version is also available on request. The beacon is particularly suitable as an attention-grabbing warning signal and for safeguarding danger spots.

Rotating Beacon;HELLA;K-LED 1.2;20W;PC (Polycarbonate);Yes;With rotating warning signal;IP 6K7K;Blue;Bolted;White;1500mm;169mm;ECE-R10;-40°C;1;LED;123mm;08A;16A;ECE-R65;24V;12V;1231/min;Silver;IP X9K;850g;1;16;+60°C;LED;Electromagnetic Compatibility (EMC);Aluminium;ADR/ GGVS Checked;
