HELLA 2RL 011 484-001 LED-Rotating Beacon - KL 7000 - 12/24V - Yellow

Item Attributes: Mounting Type: mounting / BoltedLight Design: LEDLamp Type: LEDVoltage: 12 V / 24 VOuter Diameter 1: 165 mmHeight: 119 mmLight Function: With rotating warning signalLight colour: YellowNumber of LEDs: 8Plug: Blade TerminalProt.type (IP Code): IPX9K / IP5K4KRegistration Type: ADR/GGVS / SAEFulfils ECE norm.: R10 / R65fulfils test standard: RCMSupplementary Article/Info 2: Electromagnetic Compatibility (EMC)Lens Colour: YellowHousing Colour: OrangeRotating beacon RPM: 123 1/minPower consumption: 10 WHousing material: PlasticOperating temperature from: -40 °COperating temperature to: +60 °CWeight: 670 gCable: 200 mmDiffusing Lens Material: PMMA (Polymethylmethacrylate)Reverse polarity protection: YesQuantity: 1Assembly by qualified personnel required!

The KL 7000 LED beacon is available with flashing or rotating light function. The signal is generated by means of an electronic concept and thus without moving parts. The beacon can be connected to an operating voltage of 10 - 32 V and is available as a fixed-mount variant (F) with tube socket mounting (R) or with magnetic mounting (M). The fixed version can be mounted from above and below. The product is very flat and has a scratch-resistant and dirt-resistant smooth light bonnet. The height of the beacon is approx. 119 mm (F) to 194 mm (R) depending on the design. It meets the requirements of IP5K4K and IPX9K and is therefore protected against dust and resistant to high-pressure cleaners. In addition the KL 7000 LED enables a 1:1 exchange from halogen to LED technology as it is the successor of the halogen beacon series KL 700 and KL 7000.

OE references: DAF 090 8490; LIEBHERR 1 116 977 7; ROSENBAUER FE2578; SCANIA 20 223 150; TEREX 2037.120.0018

Rotating Beacon;HELLA;KL 7000;ADR/ GGVS Checked;1231/min;ECE-R10;Yes;670g;Flachstecker;Plastic;IPX9K;1;119mm;SAE;PMMA (Polymethylmethacrylate);2RL 011 484-001;Orange;-40°C;Electromagnetic Compatibility (EMC);mounting;165mm;IP5K4K;Bolted;Yellow;+60°C;ECE-R65;8;12V;With rotating warning signal;E1 36194;200mm;10W;24V;Yellow;LED;
