HELLA 1G4 003 470-147 Halogen-Worklight - Matador - 24V

Item Attributes: Mounting Type: Screw Connection / mountingFastening Type: Four-point mountingLight Design: HalogenLamp Type: H3Voltage: 24 VHeight: 260 mmWidth: 168 mmDepth: 126 mmLight Distribution: Short distance lightingPlug: open cable endsProt.type (IP Code): IP5K4KPower consumption: 70 WSupplementary Article/Info 2: without switchHousing Type: Synthetic Material HousingHousing Colour: BlackDiffusing Lens Material: GlassDiffusing Lens Type: Patterned diffusing lensAssembly by qualified personnel required!

Together with the special honeycomb pattern in the diffusing lens the parabolic reflector enables homogeneous illumination of the working field at close range. The light source is an H3 bulb (not included in all versions). The worklight can be used (depending on the bulb) with both 12V and 24V on-board voltage. The black housing of this robust worklight is made of glass-fibre reinforced plastic. To protect the diffusing lens the housing is provided with a protruding rim at its front. The handle together with the swivel foot simplifies the adjustment of the work lights so that the working area can be optimally illuminated. The bracket enables a stable four-point attachment of the worklight. The cable entry is sealed by a grommet. Depending on the version the Matador offers additional advantages such as rotary switches (for versions -001 and -031) or protective grids (for versions -031 and -051). Article 1G4 003 470-141 is only suitable for vertical mounting as the power connection is made via an easily detachable pipe socket that fits onto push-on tubes (Ø 24 mm) for beacons.

OE references: AGCO 28761343; AUDI KDWHLO9527; BOMAG 429 095 021; BOMAG 60.028.017; CATERPILLAR 276-7694; DAF 090 6485; DAF 090 6486; DEMAG 00053012; DOLL 8998000; HITACHI 504389; IVECO 2121 801085; IVECO 5002 66328; NOOTEBOOM 2001997; REISCH 5006350; SANY B241100000243; TEREX 00053012; TEREX 94700053012; VW KDWHL09527; VW KDWHLO9527; WEIRO 17892; ZOOMLION 1020401034

Worklight;HELLA;Matador;24;Synthetic Material Housing;260mm;H3;140mm;with bulb;Vertical;Pipe-neck;168mm;Halogen;Glass;Short distance lighting;mounting;without switch;126mm;IP5K4K;1G4 003 470-147;24V;70W;
